New innovations in micro IR measurement
Explore the latest innovations in Molecular Spectroscopy and HPLC
V-700 series
UV - Visible / NIR spectrophotometers
V-730
The V-730 is a general-purpose double beam spectrophotometer with a compact space-saving design. Its excellent spectroscopic performance is suitable for routine QC, teaching and research applications.
-
Measurement wavelength range: 190nm to 1100nm
-
High performance in a compact housing
-
Ideal model for liquid measurements
-
Spectral bandwidth 1nm
V-750
The V-750 UV-Vis spectrophotometer includes a precision double-beam optical system with variable spectral bandwidth.
-
Measurement wavelength range: 190nm to 900nm
-
A wide dynamic range is achieved across the entire measurement wavelength range
-
Highly efficient and bright optical system with a single monochromator
-
By attaching various accessories, it can be used in a wide range of applications
V-760
The V-760 double beam, double monochromator optical design with lowest stray light (0.00008 %) offers high absorbance linearity across the entire photometric range.
-
Measurement wavelength range: 187nm to 900nm
-
Achieves Abs6 across a wide wavelength range
-
Double monochromator achieves class-leading extremely low stray light (0.00008%)
V-770
The V-770 offers the unique benefit of single monochromator for higher optical throughput compared to double monochromated systems. This is especially useful for diffuse and specular reflectance measurements in the NIR where signal to noise can be a problem.
-
Measurement wavelength range: 190nm to 2700nm (optionally expandable to 3200nm)
-
Highly efficient and bright optical system with a single monochromator
V-780
The V-780 has the same unique benefit as the V-770 of a single monochromator for higher optical throughput, but also has improved sensitivity from the InGaAs detector with better response in the NIR.
-
Measurement wavelength range: 190nm to 1600nm
-
High sensitivity and high resolution model using an InGaAs detector in the near infrared region
-
New lamp house improves stability in the near infrared region
MV-3000
Modular and portable
UV / Visible / NIR with a wavelength range of 200 to 1600nm
-
in-situ measurement (color diagnosis, quantitative analysis)
-
Monitoring production lines (thin films, reflectance or transmittance, turbidity measurement)
-
High-speed measurement (high-speed time-course measurement, stopped-flow kinetics, mapping measurement)
-
Emission measurement (light source evaluation, non-contact temperature measurement)
Molecular Spectroscopy
Chromatography
High-performance liquid chromatograph & supercritical fluid chromatograph
What's NEW
The Enhanced IR Microscope
JASCO IRT-5X
The new JASCO IRT-5X IR microscope is a comprehensive, versatile and productive system capable of measurements with high optical and spatial resolution.
Using this system, many of the functions that are available at the microscopic level can be used to make powerful measurements at the microscopic level. IRT-5X is extremely useful for materials identification and imaging analysis to identify components and their distribution in complex matrices.
Observation Enhancement
-
5M pixels high-resolution camera
-
High-quality observation image by an improved optical system and an electrical iris mechanism
-
Auto-focus function as standard
-
IQ Monitor for simultaneous visible image observation and IR spectrum measurement
Measurement Enhancement
-
Powerful mapping measurement with the XYZ auto-stage
-
Innovative measurement by IQ Mapping
-
Sensitivity enhancement by improvements of optics and midband MCT
-
High spatial resolution and high sensitivity measurements by IQ Duo MCT detector
-
4 detectors capability
Usability Enhancement
-
A simple and easy user interface for beginners
-
Auto sample recognition by IQ IR NAV
-
Condenser mirror slide-in mechanism
-
Reflection measurement available for a 40 mm thick sample
Welcome to the
Next Generation
Raman in the palm of your hand
PR-1w Palmtop Raman
Spectrometer
The PR-1w Palmtop Raman spectrometer is a compact unit that contains a powerful 50 mW 785 nm laser, coupled to a high resolution spectrograph with CMOS detector. Compared to many of the commercially available Raman instruments, the PR-1w is a user-friendly Raman spectrometer that can be used by virtually anyone with minimal training. It can be used in many different environments, and variety of measurement concepts, such as in-line and in-situ measurements. With a comprehensive range of optional accessories, the PR-1w can be optimized for specific applications.
Molecular Spectroscopy & Chromatography
To learn more about how JASCO technology
could assist in your research please contact us on
freephone 0800 773 274 or email: info@specsci.nz
